Product Details:
Payment & Shipping Terms:
|
| Warranty: | 3 Years | Color: | Black And White |
|---|---|---|---|
| Oem.odm: | Yes | Input: | 100-240Vac |
adapters for LED,12V 1A,1.5A,2A,3A,5A
Features :
| Model | btb1201000 | ||||||
| AC Input | AC Voltage | 90VAC(minimum)~264VAC(maximum) | |||||
| AC Frequency | 47~63Hz | ||||||
| AC Current | 0.6A max at 90Vac | ||||||
| Hold-Up time | 6msec minimum at dc output full loading and 100Vac input | ||||||
| Efficiency | ≥77.8%(At115Vac/230Vac input voltage meet Efficiency level 4) | ||||||
| Standby consume power | Less than 0.3 Watt at AC input voltage 115Vac/230Vac | ||||||
| DC Output | DC voltage | 3v-48v | |||||
| Rated current | 0.05a-2.5a | ||||||
| Current range | 0~2.5a | ||||||
| Ripple & Noise (max) | 200mVp-p | ||||||
| Rated power | 0-36w | ||||||
| Output Voltage Temperature Drift | Less then 0.2%/ °C | ||||||
| protection | Short Circuit Protection | All output will withstand a short circuit across the outputs and auto-recovery function. | |||||
| Environment | Temperature | a. Operation: 0 to 40 °C b. Storage: -40 to 70 °C | |||||
| Humidity | a. Operation: 20 to 80% b. Storage: 10 to 90% | ||||||
| Safety | EMI for both Conduction & Radiation | Referring Standards Specification: FCC(Part15,Class B) VCCI(Class B) CISPR(Part22,Class B) | |||||
| Dielectric Strength (HI-POT) TEST | Withstand AC 3000V for 60 sec. (cut off current 10mA), Primary to Secondary | ||||||
| Insulation resistance | Insulation resistance is more than 50M ohm at 500VDC between input and output plug and case. | ||||||
| Others | Certification | UL CE SAA BS FCC EMC CCC ROHS | |||||
| MTBF | The mean time between failures of power supply shall be 20000 hours or greater as calculated by parts stress method of MIL–HDBK-217F | ||||||
| Physical | Shell material: PC+ABS or PPO | ||||||
| Output cable | USB or Calbe line 1.2m/1.5m/1.8m | ||||||
| Plug | US plug/UK plug/AU plug/EU plug with copper Prong | ||||||
| DC connector | 5.5*2.1mm/5.5*2.5mm/4.0*1.7mm/3.5*1.35mm/3.5*1.0mm | ||||||
| Label | The standard label or the lable you want | ||||||
| RoHS compliance | Yes | ||||||
| Warranty Period | 2 year | ||||||
Packaging: inner box + carton, 100pcs/ctn or in accordance with the requirements of customers.
Shipping: 1.) for samples or small amount of goods, delivery by international express or air transport (shipping time: 3-5 working days). 2.) for large quantities of goods, delivery by ocean shipping SHENZHEN shipping time: 20-45 working days).
1.) All the inquiries reply less than 24 hours.
2.) Proactive and passionate pre-sale service.
3.) Patient and careful production preparation.
4.) Meticulous and perfect after-sales service.
1. We have 15 years experience in this field.
2. We offer favorable reasonable factory price.
3. We guarantee the quality of the product.
4. We have excellent research and development team.
5. We give our best after-sale service to our customers.
Applications:
MP4 players, cell phone charger.
LCD screen, Laptop ,DVR,TVB.
Digital cameras,LED and so on .
Welcome to OEM/ODM
Free sample
Sample time : 3-5days
Delivery time:7-10days
Trade terms: FOB shenzhen
Payment : T/T ,L/C,PAYPAL ,Western Union
All product warranty 3 years(One years damage manufacture one to one exchange.)
Printing you LOGO and stick you modle also ok .
