Product Details:
Payment & Shipping Terms:
|
| Color: | Black Or White | Warranty: | 3 Years |
|---|---|---|---|
| OEM: | Yes | Dc Cable: | 1.2m 1.5m 1.8m 2m |
| DC Plug: | For You Choose | Certificate: | CE FCC ROHS |
Specification:
| Oupt power range | 12v2a ,24v1a(the models for selection) |
| The adapter size | 96*44*28.5 MM(L'W'H') |
| The adapter weight | 0.22g/pcs |
| Input Rated Voltage | 86Vac~264Vac |
| Input Frequency Range | 47Hz~63Hz |
| Input Current | less than 0.5A |
| Input Inrush Current | less than 50A |
| Efficiency | 80%(MIN)at Rated Voltage |
| DC Output Voltage | 24V± 5% |
| DC Output Current | 1A |
| DC Output Power | 24w |
| Leakage Current | less than 1mA |
| Standby power | less than 0.5w |
| DC connector | 5.5*2.1*11mm (optional) |
| DC cable | 1.5m cable (optional) |
| Ripple and Noise | less than 120Mv at full road with 20MHz bandwidth |
| Turn On Delay Time | less than 3S (AC:110V and full load) |
| Certificates | CE GS UL/CUL FCC ROHS |
| Dielectric Voltage | A IEC320 three pin input---output(FG)3000Vac one minute |
| Safety protection | output voltage protection (150%-180% rated output current) |
| output current protection (150%-180% rated output current) | |
| short current protection | |
| Operating Temperature | 0°C - +55°C |
| Storage Temperature | -20°C - +85°C |
| Certificates | CE GS UL/CUL FCC ROHS |
Packing
Welcome to OEM/ODM
Free sample
Sample time : 3-5days
Delivery time:7-10days
Trade terms: FOB shenzhen
Payment : T/T ,L/C,PAYPAL ,Western Union
All product warranty 3 years(One years damage manufacture one to one exchange.)
Printing you LOGO and stick you modle also ok .
